FSRA 2012 vehicle

After a full season dedicated to the concept design of the car, which earned third place at the competition in Silverstone, the Road Arrow team began building its first race car. Less than a year passed between the detailed design and the car’s first test. “Road Arrow 2012” laid the foundations for every car that followed: a tubular steel space frame powered by the engine of a Yamaha YZF R6 motorcycle. In terms of design, the car carried the colours of the Serbian flag: white bodywork with red and blue details.

Powertrain

Engine displacement:599 cm³
Intake restrictor diameter:20 mm
Maximum power:47 kW (64 hp) at 13,000 rpm
Maximum torque:45 Nm at 9,000 rpm

Performance

Acceleration 0–100 km/h:4.9 s
Top speed:116 km/h
Transmission:6-speed sequential, electronic actuation

Chassis Structure

Vehicle mass:308 kg
Chassis:Tubular space frame, Č4580 steel
Bodywork:Glass fibre

Chassis Dimensions

Wheelbase:1600 mm
Rear track:1250 mm
Front track:1300 mm
Rims:7×13″ aluminium
